function [cfarout, threshold] = Run()

%% 1. 基础参数设置

Fs = 10e6; % 采样率 10 MHz

T_total = 1000e-6; % 总时长 1000 μs

t = (0:1/Fs:T_total-1/Fs).'; % 时间序列

% 目标参数：[时间(μs), 幅度]

targets = [

50, 0.6;

100, 0.7;

200, 0.8;

300, 0.85;

400, 1.0; % 主峰

450, 0.75;

600, 0.7;

700, 0.9;

750, 0.95;

900, 0.65

];

%% 2. 生成带杂波噪声的回波信号

sig_target = zeros(size(t));

pulse_width = 1e-6; % 目标回波脉冲宽度 1 μs

for i = 1:size(targets,1)

t0 = targets(i,1)*1e-6; % 目标时间点（转秒）

amp = targets(i,2);

sig_target = sig_target + amp * exp( -((t - t0)/pulse_width).^2 );

end

% 加入杂波和噪声

rng(1); % 固定随机种子，保证每次仿真结果一致

clutter = 0.3 * filter(ones(1,50)/50, 1, randn(size(t)));

noise = 0.1 * randn(size(t));

carout = sig_target + clutter + noise;

%% 3. CA-CFAR 自适应阈值计算

N = 16; % 参考单元数（前后各8个）

Guard = 4; % 保护单元数（前后各2个）

Pfa = 1e-3; % 虚警概率

alpha = N*(Pfa^(-1/N)-1); % CA-CFAR 缩放系数

threshold = zeros(size(carout));

len = length(carout);

for i = 1:len

% 取参考窗范围

idx_start = max(1, i - N/2 - Guard);

idx_end = min(len, i + N/2 + Guard);

% 排除保护单元

ref_idx = [idx_start:i-Guard-1, i+Guard+1:idx_end];

ref_idx = ref_idx(ref_idx >= 1 & ref_idx <= len);

if ~isempty(ref_idx)

noise_power = mean(abs(carout(ref_idx)).^2);

threshold(i) = alpha * noise_power;

else

threshold(i) = 0.5;

end

end

%% 4. 生成检测结果 cfarout

cfarout = double(abs(carout).^2 > threshold);

end
