HM-3420教程：Create Bolt Connectors创建螺栓连接器

HM-3420: Create Bolt Connectors(HM-3420:创建螺栓连接器)

In this tutorial you will learn how to apply a bolted connection to two rear trusses.(在本教程中，您将学习如何应用螺栓连接到两个后桁架。)

The Bolt panel creates connectors based on holes with in the connected components, using spiders or washers at each end of an RBE connector. When the Bolt panel is active, only bolt-type connectors display   in the graphics area; graphics for other connector types are suppressed until you exit the panel. (螺栓面板基于连接组件中的孔创建连接器，使用蜘蛛或垫圈在RBE连接器的每一端。当螺栓面板激活时，只有螺栓类型的连接器显示在图形区;在退出面板之前，其他连接器类型的图形将被抑制。)

The Bolt panel contains three   subpanels:

   。 Bolt: Create and realize bolt connectors in a single process

   。Create: Create, but not realize, bolt connectors

   。Realize: Create FE representations of previously-created bolt connectors

   （螺栓 面板 包含三个子面板:_

。创建和实现螺栓连接器在一个单一的过程?

。创建:创建但不实现螺栓连接器

。 实现:创建前面创建的螺栓连接器的FE表示）

This exercise uses the frame_assembly_2.hm file  , which can be fou
