实战：Face-API实现人脸识别（附源代码，浏览器端）

计算机视觉研究院专栏

作者：Edison_G

参考face-api.js https://github.com/justadudewhohacks/face-api.js#face-api.js-for-the-browse

关注并星标

从此不迷路

计算机视觉研究院

功能

　　第一阶段实现对图片中人脸的识别并打上标签(比如：人名)

　　第二阶段使用摄像头实现对人物的识别，比如典型的应用做一个人脸考勤的系统

资源

• face-api.js https://github.com/justadudewhohacks/face-api.js/

　　Face-api.js 是一个 JavaScript API，是基于 tensorflow.js 核心 API 的人脸检测和人脸识别的浏览器实现。它实现了一系列的卷积神经网络（CNN），针对网络和移动设备进行了优化。

• filepond https://github.com/pqina/filepond

　　是一个 JavaScript 文件上传库。可以拖入上传文件，并且会对图像进行优化以加快上传速度。让用户体验到出色、进度可见、如丝般顺畅的用户体验。确实很酷的一款上传图片的开源产品。

• fancyBox https://fancyapps.com/fancybox/3/

　　是一个 JavaScript 库，它以优雅的方式展示图片，视频和一些 html 内容。它包含你所期望的一切特性 —— 支持触屏，响应式和高度自定义。

设计思路

1. 准备一个人脸数据库，上传照片，并打上标签（人名），最好但是单张脸的照片，测试的时候可以同时对一张照片上的多个人物进行识别；
2. 提取人脸数据库中的照片和标签进行量化处理，转化成一堆数字，这样就可以进行比较匹配；
3. 使用一张照片来测试一下匹配程度。

代码具体实践步骤

还是先来看看代码吧，做这类开发，并没有想象中的那么难，因为难的核心别人都已经帮你实现了，所以和普通的程序开发没有什么不同，熟练掌握这些api的方法和功能就可以做出非常实用并且非常酷炫的产品。

1、准备素材：下载每个人物的图片进行分类

2、上传服务器数据库

3、测试

Face Landmark Detection

Face Recognition

Face Expression Recognition

Running the Examples

Clone the repository:

git clone https://github.com/justadudewhohacks/face-api.js.git

Running the Browser Examples

cd face-api.js/examples/examples-browsernpm inpm start

Browse to http://localhost:3000/.

Running the Nodejs Examples

cd face-api.js/examples/examples-nodejsnpm i

Now run one of the examples using ts-node:

ts-node faceDetection.ts

Or simply compile and run them with node:

tsc faceDetection.tsnode faceDetection.js

代码·解析

　　这里对face-api.js类库代码做一下简单的说明。

function dodetectpic() {      $.messager.progress();      //加载训练好的模型（weight，bias）      Promise.all([        faceapi.nets.faceRecognitionNet.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        faceapi.nets.faceLandmark68Net.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        faceapi.nets.faceLandmark68TinyNet.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        faceapi.nets.ssdMobilenetv1.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        faceapi.nets.tinyFaceDetector.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        faceapi.nets.mtcnn.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        //faceapi.nets.tinyYolov.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights')      ]).then(async () => {        //在原来图片容器中添加一层用于显示识别的蓝色框框        const container = document.createElement('div')        container.style.position = 'relative'        $('#picmodal').prepend(container)        //先加载维护好的人脸数据(人脸的特征数据和标签，用于后面的比对)        const labeledFaceDescriptors = await loadLabeledImages()        //比对人脸特征数据        const faceMatcher = new faceapi.FaceMatcher(labeledFaceDescriptors, 0.6)        //获取输入图片        let image = document.getElementById('testpic')        //根据图片大小创建一个图层，用于显示方框        let canvas = faceapi.createCanvasFromMedia(image)        //console.log(canvas);        container.prepend(canvas)        const displaySize = { width: image.width, height: image.height }        faceapi.matchDimensions(canvas, displaySize)        //设置需要使用什么算法和参数进行扫描识别图片的人脸特征        const options = new faceapi.SsdMobilenetv1Options({ minConfidence: 0.38 })        //const options = new faceapi.TinyFaceDetectorOptions()        //const options = new faceapi.MtcnnOptions()        //开始获取图片中每一张人脸的特征数据        const detections = await faceapi.detectAllFaces(image, options).withFaceLandmarks().withFaceDescriptors()        //根据人脸轮廓的大小，调整方框的大小        const resizedDetections = faceapi.resizeResults(detections, displaySize)        //开始和事先准备的标签库比对，找出最符合的那个标签        const results = resizedDetections.map(d => faceMatcher.findBestMatch(d.descriptor))        console.log(results)        results.forEach((result, i) => {          //显示比对的结果          const box = resizedDetections[i].detection.box          const drawBox = new faceapi.draw.DrawBox(box, { label: result.toString() })          drawBox.draw(canvas)          console.log(box, drawBox)        })        $.messager.progress('close');        })      }//读取人脸标签数据    async function loadLabeledImages() {      //获取人脸图片数据,包含：图片+标签      const data = await $.get('/FaceLibs/GetImgData');      //对图片按标签进行分类      const labels = [...new Set(data.map(item => item.Label))]      console.log(labels);      return Promise.all(        labels.map(async label => {          const descriptions = []          const imgs = data.filter(item => item.Label == label);          for (let i = 0; i < imgs.length; i++) {            const item = imgs[i];            const img = await faceapi.fetchImage(`${item.ImgUrl}`)            //console.log(item.ImgUrl, img);            //const detections = await faceapi.detectSingleFace(img).withFaceLandmarks().withFaceDescriptor()            //识别人脸的初始化参数            const options = new faceapi.SsdMobilenetv1Options({ minConfidence:0.38})            //const options = new faceapi.TinyFaceDetectorOptions()            //const options = new faceapi.MtcnnOptions()            //扫描图片中人脸的轮廓数据            const detections = await faceapi.detectSingleFace(img, options).withFaceLandmarks().withFaceDescriptor()            console.log(detections);            if (detections) {              descriptions.push(detections.descriptor)            } else {              console.warn('Unrecognizable face')            }          }          console.log(label, descriptions);          return new faceapi.LabeledFaceDescriptors(label, descriptions)        })      )      }

face-api 类库介绍

face-api 有几个非常重要的方法下面说明一下都是来自 https://github.com/justadudewhohacks/face-api.js/ 的介绍在使用这些方法前必须先加载训练好的模型,这里并不需要自己照片进行训练了，face-api.js应该是在tensorflow.js上改的所以这些训练好的模型应该和python版的tensorflow都是通用的。所有可用的模型都在https://github.com/justadudewhohacks/face-api.js/tree/master/weights 可以找到。

//加载训练好的模型（weight，bias）// ageGenderNet 识别性别和年龄// faceExpressionNet 识别表情,开心，沮丧，普通// faceLandmark68Net 识别脸部特征用于mobilenet算法// faceLandmark68TinyNet 识别脸部特征用于tiny算法// faceRecognitionNet 识别人脸// ssdMobilenetv1 google开源AI算法除库包含分类和线性回归// tinyFaceDetector 比Google的mobilenet更轻量级，速度更快一点// mtcnn 多任务CNN算法，一开浏览器就卡死// tinyYolov2 识别身体轮廓的算法，不知道怎么用      Promise.all([        faceapi.nets.faceRecognitionNet.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        faceapi.nets.faceLandmark68Net.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        faceapi.nets.faceLandmark68TinyNet.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        faceapi.nets.ssdMobilenetv1.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        faceapi.nets.tinyFaceDetector.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        faceapi.nets.mtcnn.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights'),        //faceapi.nets.tinyYolov.loadFromUri('https://raw.githubusercontent.com/justadudewhohacks/face-api.js/master/weights')      ]).then(async () => {})

非常重要参数设置，在优化识别性能和比对的正确性上很有帮助，就是需要慢慢的微调。

SsdMobilenetv1Optionsexport interface ISsdMobilenetv1Options {  // minimum confidence threshold  // default: 0.5  minConfidence?: number    // maximum number of faces to return  // default: 100  maxResults?: number}  // exampleconst options = new faceapi.SsdMobilenetv1Options({ minConfidence: 0.8 })TinyFaceDetectorOptionsexport interface ITinyFaceDetectorOptions {  // size at which image is processed, the smaller the faster,  // but less precise in detecting smaller faces, must be divisible  // by 32, common sizes are 128, 160, 224, 320, 416, 512, 608,  // for face tracking via webcam I would recommend using smaller sizes,  // e.g. 128, 160, for detecting smaller faces use larger sizes, e.g. 512, 608  // default: 416  inputSize?: number    // minimum confidence threshold  // default: 0.5  scoreThreshold?: number}  // exampleconst options = new faceapi.TinyFaceDetectorOptions({ inputSize: 320 })MtcnnOptionsexport interface IMtcnnOptions {  // minimum face size to expect, the higher the faster processing will be,  // but smaller faces won't be detected  // default: 20  minFaceSize?: number    // the score threshold values used to filter the bounding  // boxes of stage 1, 2 and 3  // default: [0.6, 0.7, 0.7]  scoreThresholds?: number[]    // scale factor used to calculate the scale steps of the image  // pyramid used in stage 1  // default: 0.709  scaleFactor?: number    // number of scaled versions of the input image passed through the CNN  // of the first stage, lower numbers will result in lower inference time,  // but will also be less accurate  // default: 10  maxNumScales?: number    // instead of specifying scaleFactor and maxNumScales you can also  // set the scaleSteps manually  scaleSteps?: number[]}  // exampleconst options = new faceapi.MtcnnOptions({ minFaceSize: 100, scaleFactor: 0.8 })

最常用的图片识别方法，想要识别什么就调用相应的方法就好了。

// all facesawait faceapi.detectAllFaces(input)await faceapi.detectAllFaces(input).withFaceExpressions()await faceapi.detectAllFaces(input).withFaceLandmarks()await faceapi.detectAllFaces(input).withFaceLandmarks().withFaceExpressions()await faceapi.detectAllFaces(input).withFaceLandmarks().withFaceExpressions().withFaceDescriptors()await faceapi.detectAllFaces(input).withFaceLandmarks().withAgeAndGender().withFaceDescriptors()await faceapi.detectAllFaces(input).withFaceLandmarks().withFaceExpressions().withAgeAndGender().withFaceDescriptors()  // single faceawait faceapi.detectSingleFace(input)await faceapi.detectSingleFace(input).withFaceExpressions()await faceapi.detectSingleFace(input).withFaceLandmarks()await faceapi.detectSingleFace(input).withFaceLandmarks().withFaceExpressions()await faceapi.detectSingleFace(input).withFaceLandmarks().withFaceExpressions().withFaceDescriptor()await faceapi.detectSingleFace(input).withFaceLandmarks().withAgeAndGender().withFaceDescriptor()await faceapi.detectSingleFace(input).withFaceLandmarks().withFaceExpressions().withAgeAndGender().withFaceDescriptor()

Detecting Faces

Detect all faces in an image. Returns Array<FaceDetection>:

const detections = await faceapi.detectAllFaces(input)

Detect the face with the highest confidence score in an image. Returns FaceDetection | undefined:

const detection = await faceapi.detectSingleFace(input)

By default detectAllFaces and detectSingleFace utilize the SSD Mobilenet V1 Face Detector. You can specify the face detector by passing the corresponding options object:

const detections1 = await faceapi.detectAllFaces(input, new faceapi.SsdMobilenetv1Options())const detections2 = await faceapi.detectAllFaces(input, new faceapi.TinyFaceDetectorOptions())

具体可以参考官方Github具体步骤！
