ANSYS Workbench怎么和Creo联动？通用关联方法搞懂仿真数据无缝衔接

ANSYS 关联Creo=======

1.0 Ansys 设置

D:\Program Files\ANSYS Inc\v222\aisol\CADIntegration\ProE\ProEPages\config\WBPlugInPE.dat

文件应该显示：====================

NAME WB222PluginProWF

EXEC_FILE D:\Program Files\ANSYS Inc\v222\aisol\CADIntegration\ProE\winx64\WBPlugInCreo7COM.dll

TEXT_DIR D:\Program Files\ANSYS Inc\v222\aisol\CADIntegration\ProE\ProEPages\Language\en-us

STARTUP dll

delay_start FALSE

allow_stop TRUE

REVISION ProEWildfire

END

NAME ac4pro222dll

exec_path D:\Program Files\ANSYS Inc\v222\ANSYS\ac4\bin\pro\winx64\ac4pro_creo7.exe

text_path D:\Program Files\ANSYS Inc\v222\ANSYS\ac4\data\pro\text

STARTUP dll

delay_start FALSE

allow_stop TRUE

unicode_encoding FALSE

revision 24.0

end

==================================

2. Creo 设置

D:\Program Files\PTC\Creo 9.0.2.0\Common Files\text\config.pro

文件应该显示：====================

drawing_setup_file $PRO_DIRECTORY\text\prodetail.dtl

format_setup_file $PRO_DIRECTORY\text\prodetail.dtl

pro_unit_length unit_inch

pro_unit_mass unit_pound

template_designasm $PRO_DIRECTORY\templates\inlbs_asm_design_abs.asm

template_new_ecadasm $PRO_DIRECTORY\templates\inlbs_ecad_asm_abs.asm

template_drawing $PRO_DIRECTORY\templates\c_drawing.drw

template_sheetmetalpart $PRO_DIRECTORY\templates\inlbs_part_sheetmetal_abs.prt

template_solidpart $PRO_DIRECTORY\templates\inlbs_part_solid_abs.prt

template_boardpart $PRO_DIRECTORY\templates\inlbs_ecad_board_abs.prt

todays_date_note_format %Mmm-%dd-%yy

tolerance_standard ansi

weld_ui_standard ansi

search_path_file $CREO_COMMON_FILES\ifx\parts\prolibrary\search.pro

PROTKDAT D:\Program Files\ANSYS Inc\v222\aisol\CADIntegration\ProE\ProEPages\config\WBPlugInPE.dat

=================================================================
